• Model NO.：1B1209
• N.W.：2.0 Kg
• Pressure Ability：0.2-0.8 M PA
• Air Inlet：G3,4
• Top Plate Hole/Stud：M8
• Bottom Plate Hole/Stud：M8
• Top Plate Dia：135 mm
• Bottom Plate Dia：135 mm
• Transport Package：Cartons
• Specification：24*24*22 cm
• Trademark：Neutral
• Origin：China
• HS Code：8708809000
• Production Capacity：5000PCS,Month

Force F [lbf]Pressure p [psi]406080100Vol. V [in.³]H 4.50 in./114.3MM728113015701970110H 4.00 in./101.6MM905140019402390100H 3.50 in./88.9MM105016102240274090H 3.00 in./76.2MM117017702450302075H 2.50 in./63.5MM127019002630326057



VIBRATION ISOLATION - DYNAMIC CHARACTERISTICS



Pressure p [psi]406080100120Vol. V [in.³]Force (load) F [lbf]8011,2401,7002,1302,530110Spring rate c [lbf/in]7099491,1901,4301,670110Natural Frequency f0 [Hz]2.92.82.72.62.6110Design height H: recommended 4.33 inch, minimum 3.54 inch
