• Model NO.：97034305134 97034305234, 2H 5134 2H 5234
• Spring Material：Rubber
• Structure：Single Cylinder
• Car Make：Porsches
• Brand：HONGGU
• Damping Force Direction：Single Effect
• Weight：8KG
• Application：Porsches 970 Panamera 2014-2017
• Color：Sliver and Black
• Size：Original Standard
• Bushing Material：EPDM
• Usage：Auto
• Sample：Available
• Deliverry Time：3-7 Days
• Car Model：Porsches 970 Panamera
• Shock Absorber Type：Hydraulic air Shock Absorber
• Year：2014-2017
• MOQ：2 PC
• Platform：Porsches 970 Panamera
• Transport Package：Neutral Packing with Strong Carton Box,or Warped W
• Specification：73*21*20CM
• Trademark：HONGGU
• Origin：Guangdong China
• Production Capacity：4000 PCS,Month

OE NO.23290660Warranty12 MonthPlace of OriginChinaChinaGuangdongBrand NameHONGGUCar ModelFor Chevy Tahoe Suburban Cadillac Escalade ESV GMCProduct nameAir Shock AbsorberTypeFor Chevy Tahoe Suburban Cadillac Escalade ESV GMC YukonApplicationAuto Suspension PartsMaterialSteel+Aluminum+RubberOEMOEM StandardPaymentTT.paypal.Western Union.Trade AssuranceQuality100% TestedDelivery time3-5 Working DaysPackingNeutral PackingOE Number84176675 580-1106 580-1068 23151122 23267007 23290661 23290660

Air Suspension

An air suspension system is a style of vehicle suspension that's powered by an electric pump or compressor that pumps air into flexible bellows that are typically made out of a textile-reinforced type of rubber. Additionally, Pro Car Mechanics describes air suspension as a replacement to the leaf suspension or coil spring system with airbags composed of polyurethane and rubber. A compressor inflates the bags to a certain pressure in order to behave like springs. Air suspension also differs from hydro pneumatic suspension because it uses pressurized air instead of pressurized liquid.

Air Spring

An air spring is a rubber and fabric bladder that holds air pressure to support a load and isolate passengers and cargo from the shock of motion caused by road irregularities. As the air pressure increases, the air spring can support more load while the spring rate increases. The larger the air spring, the greater the maximum load it can support.

Air Suspension Compressor

A device that compresses and pressurizes air. Used to inflate air springs.
An Air Suspension Compressor also called Air Compressor or Air Pump, inflates or deflates air spring bags as necessary. When a vehicle with air suspension drops below the factory-defined height, the air suspension compressor, also simply called an air compressor or air pump is activated and inflates the air bags or air struts.

Air Spring Advantage

1. Air springs increase spring rate and vastly improve vehicle stability, that means a safer and more comfortable ride.
2. Soaks up bumps, reduces the frequency of vibration while driving on the road, prevents the damage of the other parts from the heavy loading vehicles.
3. The cushioning principle is adopted, the shock absorption performance is obviously improved, and the passenger comfort is improved.

How Do You Take Care Of Air Suspension

1.To help you better take care of your vehicle, here are the top five tips for maintaining your car's air suspension system.
2.Check System for Leaks.
3.Check Air Line Connections.
4.Check the Air Springs.
5.Perform Visual Inspections and Clean Regularly.
6.Schedule Routine Service Appointments.

The 8 Steps To Install A New Air Spring On Your Vehicle

Replacing a broken air spring may require the help of a mechanic, but you can cut down your expenses by simply installing it yourself.
1: Parking your car on a level surface then using the floor jack to lift it up. Place the jack stands underneath the vehicle for support.
2: Remove the wheels by detaching its lug nuts one by one. Use a wrench for this procedure.
3: Deflate the air spring by opening the air mouth on the top.
4: Detach the set of fasteners that secure the air spring in place. You can generally find these bolts on the control arm and under the hood. Keep in mind that the set of procedures for removing an air spring vary for each car, so make it a point to consult your owner's manual to see exactly how yours is removed.
5: Remove the old air spring away from the shock carefully. If needed, use a spring compressor to make the remove easier. You may reuse the O rings connecting the air spring to the shock.
6: Put the new air spring on the place where you removed the old one.
7: Reconnect it to the shock using the O rings you removed earlier. Make sure you apply lubricant on them before putting them back.
8: Reattach all the components that you removed. Recheck if there are no missing bolts, nuts and fittings.
Are You Manufacturer Or Trading Company?We Are Specialize In Auto Parts ( Air Suspension) ManufacturerWhat's The MOQ?The MOQ With Our Standard Products Is 1 Piece.What's Your Mainly Products?We Supply Air Suspension Struts, Air Suspension Spring, Shock Absorber, Pressure Shocks, Air Pump etc.What's Your Policy On Warranty?We Provide 12 Months For New Suspension Parts Products For Our Customers.Where Is Your Company?Our Factory Located At Shunde District Foshan City.
We Warmly Welcome You To Visit Anytime, More Details & Info Please Contact UsWhat Are Your Payment Methods?We Accept T/T, Paypal, Western Union, Money Gram, Alipay. Due To Difference Payment In Difference Countries Or RegionsWhat's Your Packing Way?Neutral Packing, Standard Packing, Accept Customers' Special Required.How Do You Usually Ship The Goods And When?Normally, We Will Ship The Goods In 3-7 Days After Payment Verified And Goods Confirmed, And Ship The Goods Via The (HuangPu) Ports In GuangZhou.If You Offer The Free Sample?We Accept MOQ 1 Piece Order, But Do Not Offer The Free Sample To Our Customers.Are Your Air Suspension Struts Brand New or Remanufacturing?Our air suspension/air compressor/air strut/air suspension parts 100% NEWLY manufactured to instead OEMDo You Provide OEM/ODM Service?If You Want to Show your own Brand LOGO on the goods such as cable, package bag, label or any where. Our OEM and ODM service is always ready to do it.
