• Model NO.：TL-BJ005
• Transport Package：Carton and Pallet
• Specification：M44*1.5*156.5mm
• Trademark：TOLY
• Origin：China
• Production Capacity：20000pieces,Month

Basic Info.

Model NO. TL-BJ005 Transport Package Carton and Pallet Specification M44*1.5*156.5mm Trademark TOLY Origin China Production Capacity 20000pieces/Month

Product Description

Nissan Steering Knuckle Ball Joint with 48570-90214 RH  48571-90205 LH

Other Tie rod rack end for Japanese truck Nissan as below :

48570-90212 RH           48571-90212 LH	L=156.5       M44*1.5   M24*1.5	Nissan CW 53 long
48570-00Z05 RH           48571-00Z05 LH	L=218    M=49*1.5   M24*1.5	Nissan CW 450
48570-90218 RH          48571-90218 LH	L=218                       M=56*1.5   M24*1.5	Nissan CW 520
48570-90214 RH          48571-90205 LH	L=156.5                      M44*1.5   M24*1.5	Nissan RG

Components	Material 1	Material 2	Material 3
Ball housing	45# steel  Hardening and tempering	45# steel	Screw-thread steel (35# steel)
Ball pin	40Cr  Hardening and tempering	40Cr	Screw-thread steel (35# steel)
Ball cup	Carbonitriding	Hardening and tempering	Nylon
Rear cover	SGCC	SGCC	SPHC SPHE
Dust cover	Rubber	Polyurethane	Plastic
Spring	65Mn	65Mn	60Si2Mn
Nut	45# steel  hardening and tempering	45# steel	Screw-thread steel (35# steel)
Split pin	A3 gold-plate	A3 plated silver	A3 plated silver
Glib	90°	135°	180°
