• Model NO.：X480C
• Certification：ISO,TS16949
• Car Make：Volkswagen, WuLing, Benz, BMW, Hyundai, Honda, Toyota, Jeep, Nissan, Ford, Buick, Chery, Chevrolet, Cadillac, Geely, Roewe, Audi, Peugeot, Lexus, Volvo, Mazda, Kia
• Position：Rear
• OEM：Yes
• Type：Air Suspension Compressor
• Max. AMP Draw：23AMPS
• Max.Flow Rate：50L,Min(1.76cfm)
• Transport Package：Neutral Packing
• Specification：261*106*167.7mm
• Trademark：CARTEEAIR
• Origin：Guangdong Huizhou
• Production Capacity：50000
• Package size per unit product：26.10cm * 10.60cm * 16.77cm
• Gross weight per unit product：6.000kg

*Voltage: 13.8V

2.5 GALLON TANK

FILL RATE

0 to 145 PSI

2 min. 50 sec. (± 10 sec.)

110 to 145 PSI

57 sec. (± 05 sec.)

0 to 200 PSI

5 min. 02 sec. (± 10 sec.)

165 to 200 PSI

1 min. 30 sec. (± 05 sec.)

5.0 GALLON TANK

FILL RATE

0 to 145 PSI

6 min. 02 sec. (± 10 sec.)

110 to 145 PSI

1 min. 55 sec. (± 05 sec.)

0 to 200 PSI

10 min. 30 sec. (± 15 sec.)

165 to 200 PSI

3 min. 10 sec. (± 10 sec.)

IMPORTANT SAFETY INSTRUCTIONS

CAUTION - To reduce risk of electrical shock

or electrocution:

Do not disassemble. Do not attempt repairs or modifications. Refer to qualified service agencies for all service and repairs.

Do not use this product in or area where it can fall or be pulled into water or other liquids.

Do not reach for this product if it has fallen into liquid.

Use this compressor with 12-volt DC systems only.

This product should never be left unattended during use.

WARNING - To prevent injury:

Never allow children to operate this compressor. Close supervision is necessary when this compressor is being used near children.

This compressor will become very HOT during and immediately after use. Do not touch any part of this compressor with bare hands, during and immediately after use.

Do not use this product near flames or explosive materials or where aerosol products are being used.

Do not operate this product where oxygen is being administered.

Do not pump anything other than atmospheric air.

Never use this product while sleepy or drowsy.

Do not use any tools or attachments without first determining maximum air pressure for that tool or attachment.

Never point any air nozzle or air sprayer toward another person or any part of the body.

This air compressor is equipped with an Automatic Reset Thermal Protector, and can automatically restart after the thermal protector resets. Always cut off power source when thermal protector becomes activated.

Wear safety glasses or goggles when operating this product.

Use only in well ventilated areas.
