Nc Bending Machine (WC67 K 300T5000 with E200)
Shanghai Aluke Equipment Co., Ltd.- Certification：ISO9001, ISO9002, CE
- Pressure:300t：Width:5000mm
- Transport Package：Steel Tray
- Specification：International Standard
- Trademark：ALUKE
- Origin：China
Base Info
- Model NO.：WC67K 300T5000 with E200
- HS Code：846229
- Production Capacity：80 Sets,Month
Description
| Number | Name | Value | Unit | Notes | ||
| 1 | Nominal pressure | 3000 | KN | |||
| 2 | Length of workbench | 5000 | mm | |||
| 3 | Width of workbench | 300 | mm | |||
| 4 | Poles distance | 4100 | mm | |||
| 5 | Throat depth | 400 | mm | |||
| 6 | Max stroke | 250 | mm | |||
| 7 | Max open | 590 | mm | |||
| 8 | Back gauge stroke | 850 | mm | |||
| 9 | Gear pump | model | NBZ4-G40F | |||
| 10 | flow | 40 | L/min | |||
| 11 | pressure | 32 | MPa | |||
| 12 | Thickness of workbench | 60 | mm | |||
| 13 | Main power | 22 | KW | |||
| 14 | Slider speed | Up | 60 | Mm/s | ||
| Down | 10 | Mm/s | ||||
| Inflating | 60 | Mm/s | ||||
