Adb22X 802569 Air Disc Rotor with Kits

Qingdao Pujie Industry Co., Ltd.
  • After-sales Service：18 Months From Purchasing
  • Warranty：18 Months From Purchasing
  • Type：Brake Discs
  • Material：Iron
  • Position：Rear
  • Certification：ISO,TS16949, ISO9001, DOT, ECE

Base Info

  • Model NO.：Bendix 802569
  • Classification：Disc
  • Drum Brakes Classification：Truck Brake Disc
  • Main Market：Northern Europe
  • Height：45 mm
  • PCD：165.1mm
  • No. of Holes：10
  • Centering Diameter：258 mm
  • Brake Discs Thickness：37mm
  • Brake Discs Type：Vented
  • Fitting Position：Rear
  • Delivery：Fast
  • Min . Thickness：37mm
  • Transport Package：Neutral Packing or at Buyer′s Request
  • Specification：CE, SGS, ISO, TS16949, E-mark, EAC
  • Trademark：Pujie
  • Origin：Qingdao, China
  • HS Code：8708309500
  • Production Capacity：300, 000 PCS,Year

Description

CHEMICAL COMPOSITION (mass %)MnNiCrMoCuSPSnTiV0.4/0.15/0.3/////0.80.10.350.250.60.150.10.150.050.05MICROSTRUCTUREMATRIXType of matrixFine LamellarPermissible limit5% Max, well distributedLedebutiteNot permissibleGRAPHITE (To UNI EN ISO 945)Shape∣DistributionA: 70% MIND·E:<4% DisporsedB: Resto/RemainderSize3- 4 -5 : 70% MIN2: Traces6:≤15%Cementite and free carbidesTraces uo pt 1% MAX permissibleMECHANICAL PROPERTIES OF CASTINGHARDNESS (HBW)On machined braking surfaces170~210On braking surfaces as-cast (0.5 mm below surface)230MAXTENSILE STRENGTH(Rm) (N/m²)On braking surface170 MINOn mounting flangeWEDGE INDENTATION STRENGTH (Rmk)(N/m²)On braking surface125 MINYoung's MODULUS (E) (N/m²)/95PHYSICAL PROPERITIESDensity7.1 kg/dm³Coefficient of thermal exoansion at 20 degree9.10 1/KThermal conductivity at 100 degree50 W/Mk

2. About us :

Qingdao Pujie Industry Co., Ltd. is a worldwide leader, specializing in disc brake pads and shoes,brake discs and drums for all makes and models of passenger and commercial vehicles. PUJIE continuously strives for high level of customer satisfaction, by maintaining high quality raw material, advance production technology and fast delivery.
   PUJIE products are manufactured under ISO/TS 16949 & ISO 9001 certifications to ensure the highest level of quality.

3. Our Strength  :

1.)Wide range of brake parts :

We can supply you a geart variety of brake parts , such brake shoes, brake rotors , brake discs and so forth . You name the O.E. No. , we can give you what you need for sure .

2.)Better price :

This is our customers cares most . And I believe you care the question ,too . What I can assure you is that we can save you 10% of your production line , both domestically or any other circumstance .

3.)Top service :

We can cope with all the circumstances that we encounter and can fix the problem immediately . Our team are all have expertise knowledge . With that , I think there is nothing to worry about .

 4. Part of numbers we have :

APPLICATIONMeritor
NOVA Bus/BCI Drive Axle Bendix Knorr SB-7/SN-7M44D76612  MBR5032
Haldex DB22 and DB22LTM44D6206
Bendix/Knorr ADB22X/ADB225M44D76617
 M44D76613
ADB22XM44D76692
ELSA, EX22523-123647-002
Prevost Font and Tag Bendix Knorr SB7 / SN7M44D76641
Bendix/Knorr ADB22X/ADB225M44D76618
Prevost Front and Tag Bendix Knorr SB-7/SN7M44D76603
 M44AD75180
Bendix Knorr SN-7M44D76642
 23123642002
 M44D71601
Prevost Drive Bendix Knorr SB-7/SN-7M44D76604
 TDA 3218K167
ROTOR REAR CM HUBTDA 3218Z156
 TDA 3218Z1404/123547
 TDA 23123647002
 TDA 68326014
 TDA 3218A1145
 TDA 3218Y1065
 68323736, 68325977
 68323012/68325978/MBR9013
VOLVO 20564467Setra A6274210012, 6231000870
 M44D76690
 M44D76691
 M44DH41216
 M44DH41217
