082 Air Suspension Kit Air Compressor for Air Suspension Inflatable Products The Move Tool
Huizhou Cartee Electric & Machinery Co., Ltd.- After-sales Service：1 Year Warranty
- Warranty：1 Year Warranty
- Material：Copper, Iron
- Certification：ISO,TS16949, ISO9001
- Car Make：Carteeair
- OEM：Yes
Base Info
- Type：Air Suspension Compressor
- Color：Chrome
- Max. Working Pressure：120 Psi
- Max. Flow Rate：36L,Min (1.27cfm)
- Duty Cycle：9% @ 100 Psi
- Transport Package：Box
- Trademark：CARTEEAIR
- Origin：China
Description
12-Volt CompressorPSI LPM CFM AMP 0 36 1.27 5 10 24 0.85 6 20 23 0.81 7 30 21 0.74 8 40 19 0.67 8 50 17 0.60 8 60 16 0.57 9 70 15 0.53 9 80 13 0.46 9 90 12 0.42 9 100 11 0.39 9 110 10.5 0.37 9 120 10 0.35 * Supply Voltage: 13.8 Volts
CARTEEAIR offers the most comprehensive line of 12-volt and 24-volt air compressors for both the on-and off road markets available anywhere. Our quality engineered compressors and components are also used in the OEM segment, and have become the industry standard for automotive aftermarket applications worldwide.
Note: • Always operate the compressor at or below the MAXIMUM PRESSURE RATING of the air compressor. Always observe the MAXIMUM DUTY CYCLE of the air compressor. Operation exceeding maximum pressure ratings and/or duty cycle will result in damage to the air compressor.
• Max. operating temperature: +158°F, • Min. operating temperature: -40°F (unless otherwise noted).
CARTEEAIR offers the most comprehensive line of 12-volt and 24-volt air compressors for both the on-and off road markets available anywhere. Our quality engineered compressors and components are also used in the OEM segment, and have become the industry standard for automotive aftermarket applications worldwide.
Note: • Always operate the compressor at or below the MAXIMUM PRESSURE RATING of the air compressor. Always observe the MAXIMUM DUTY CYCLE of the air compressor. Operation exceeding maximum pressure ratings and/or duty cycle will result in damage to the air compressor.
• Max. operating temperature: +158°F, • Min. operating temperature: -40°F (unless otherwise noted).
